Product Details
1、A New Energy-Saving Force Dual Grade-1 Efficiency for Heating & Hot Water
2、Dual Inverter Technology Precise temperature control for greater comfort
3、Up to 16L Smart High Water Output Worry-free bathing for the whole family
4、Full Premix Condensing Technology Heating efficiency up to 108% Saves up to 31% gas
5、Quiet Operation Without Disturbance Library-level silence experience
6、6-Year Full Unit Warranty Worry-free after-sales support
Product Parameters
Heating
| Product Model | LL1GBQ25-Y3 | LL1GBQ30-Y3 | 单位 |
| Recommended Heating Area | 60~200 | 80~280 | m² |
| Gas Type | NG(12T) | NG(12T) | |
| Energy Efficiency Rating | Grade 1 Energy Efficiency | Grade 1 Energy Efficiency | |
| Thermal Efficiency | >107 | >107 | % |
| Rated Heating Load | 25.3 | 29.5 | kW |
| Minimum Heating Load | 4.5 | 4.5 | kW |
| Dimensions (L × W × D) | 704x403x252 | 704x403x252 | mm |
DHW
| Hot Water Output Capacity (Δt = 25K) | 16.0 | 16.0 | kg/min |
| Minimum Domestic Hot Water Output | 4.1 | 4.1 | kW |
